Discrete Multibit PowerDACs and Accessories

PowerDAC-X Series Philosophy R & D

PowerDAC-SX

Digital audio set with integrated lossless volume control and discrete multibit fractal-15 bridge matrix DA converter intended for driving speakers and balanced headphones.



Link to Audiophile Heaven review ECdesigns PowerDAC-SX Stereo HIFI Integrated DAC – Ultimate Levels Of Power And Control



YouTube

Flagship DAC That Can Drive Speakers – ECDesigns PowerDAC-SX Review



PowerDAC-BX

Basic DAC with discrete multibit fractal-7 matrix DA converter mainly intended for driving (pre) amps.

Discrete Multibit PowerDACs

PowerDAC-SX + IRC

€ 3.450,00

Digital audio set with integrated lossless volume control and discrete multibit fractal-15 bridge matrix DA converter intended for driving speakers and balanced headphones.

SKU: POWERDAC-SX+IRC Category:
Read more

PowerDAC-RXV

€ 1.350,00

Desktop DAC with integrated lossless volume control and discrete multibit fractal-7 matrix DA converter primarily intended for driving headphones and power amps.

SKU: powerdac-rxv Category:
Read more

PowerDAC-RX

€ 1.250,00

Universal DAC with integrated lossless volume control and discrete multibit fractal-7 matrix DA converter primarily intended for driving power amps.

SKU: POWERDAC-RX Category:
Read more

PowerDAC-BX

€ 995,00

Basic DAC with discrete multibit fractal-7 matrix DA converter mainly intended for driving (pre) amps.

SKU: POWERDAC-BX Category:
Read more

Accessories

UT96

€ 125,00

UT96 USB to Toslink converter
The UT96 is a USB to Toslink/ ElectroTos converter.

SKU: UT96 Category:
Read more

UT192

€ 325,00

UT192 USB to Toslink converter
The UT192 is a high speed USB to Toslink/ ElectroTos converter

SKU: UT192 Category:
Read more

RCA625

€ 50,00

–

SKU: rca625 Category:
Read more

RCA35

€ 40,00

RCA to 3.5mm headphone cable

SKU: rca35 Category:
Read more

IRC Remote Control for PowerDAC-R/RX/RXV/SX

€ 150,00

The PowerDAC-R/RX/SX have a built-in IR receiver to adjust volume and muting using the IRC Remote Control for PowerDAC-R/RX/RXV/SX.
The built-in battery can be recharged using USB 5V though a USB mini cable.

SKU: rc Category:
Read more

ET400

€ 70,00

ElectroTos cable 4 mtr.

SKU: et400 Category:
Read more

ET300

€ 60,00

ElectroTos cable 3 mtr.

SKU: et300 Category:
Read more

ET200

€ 50,00

ElectroTos cable 2 mtr.

SKU: et200 Category:
Read more

ET100

€ 40,00

ElectroTos cable 1 mtr.

SKU: et100 Category:
Read more

AI200

€ 100,00

SKU: ai200 Category:
Read more

AI100

€ 75,00

Audio Interlink cable 1 mtr.

SKU: ai100 Category:
Read more

Browse Categories

Latest blog posts

YouTube PowerDAC-SX Review
20
Oct
PowerDAC-SX review 26-07-2024
29
Jul
No Amplifiers here.
11
Jul
PowerDAC-SX and Speakers
08
Jun
Audio interfaces and sound quality
08
May
USB to Toslink and ElectroTos converters
25
Apr
ElectroTos
24
Apr

PowerDAC - X Series

Conventional DACs always have lossy analogue circuits and components in the signal path for converting, amplifying and buffering in order to drive the load.

These analogue components will cause degrading, this degrading barely shows up on static THD measurements but becomes clearly audible with complex dynamic music related signals. This is why audio components with superb technical specs can still fail to simply offer consistent, transparent, involving music reproduction as music is more complex than reproducing tones. With both, the PowerDAC and PowerDAC-X series we removed these lossy analogue circuits and components using discrete multibit DA converters that are powerful enough to directly drive loads. These power DA converters only contain a power source, bit switches and a resistor array that connects to the load. The fractal system lowers output impedance, improves accuracy and minimises glitches, glitches occur when a new sample is generated and the output is undefined (distorts) for a very short moment. In order to improve things further we also integrated a lossless volume control that adds no extra components to the signal path (programmable DA supply voltage and bit shifting). The new X series (X stands for matriX) further tackles the glitch problem by only switching the lowest bits during the signal zero crossing and gradually switching higher bits as signal value increases. Other typical DAC issues are jitter and source / ground loop noise, every single component or part seems to have some impact on perceived sound quality. These problems are tackled by our unique DAPI (Digital Audio Parallel Interface) Toslink receiver that has an independent local low jitter masterclock and a parallel data interface for driving the DA converters.

Philosophy

Every component in the signal path is imperfect and introduces extra degradation, non-linear components or circuits are especially problematic.

The degradation doesn’t only consist of distortion and noise but it also causes clearly audible temporal (dynamic) distortion and limited resolution. Compare this with a gearbox having mechanical play, causing incorrect positioning, rattling during operation and faillure to track very small input axle movements. While running in one direction, output accuracy seems fine (compare this to a 1 KHz THD measurement) but when the rotation speed and direction keeps changing constantly and rapidly (compare this with music) the output axle won’t accurately track the movement and rattles (noise). If the input axle movement is small compared to the backlash, the output axle won’t even move or produces a very large error (compare this with low level signals in an audio set). Audio components with low THD and noise can still fail in the temporal distortion or resolution department, causing clearly audible distortion and or lack of refinement that theoretically shouldn’t happen. When cascading multiple gearboxes (multiple components in an audio set or signal path) these problems even get worse. So it is logical to limit the amount of circuits or components in the signal path to an absolute minimum. Because distortion is cumulative (every extra component or part adds distortion) and the signal gets amplified it is wise to make the source (microphone, record, tape, DAC) as perfect as possible (the most important link in the audio set). We developed a DA converter that works with a power supply, switches (on or off) and resistors (linear components) exclusively, creating the shortest and most accurate practical signal path. This way we tackled distortion on all fronts (non-linear distortion, temporal distortion and loss of resolution). The virtually ideal solution (PowerDAC-S, PowerDAC-SX) skips the conventional analogue signal path and all related degrading by converting lossless digital information into an analogue signal at the end of the lossless digital signal path, just before the signal is presented to the speaker. Typical problems with digital circuits like jitter and (ground loop) noise were tackled by our Toslink DAPI receiver that provides perfect galvanic isolation, attenuates incoming noise, re-times all samples with a local, low jitter master clock. The DA converter is driven with a parallel digital audio interface.


R & D

For many years we have been researching, improving and selling our discrete DACs and related products. This has resulted in new products nearly every year. We improved R2R with R4R (Mosaic series), created clean source (UPL96/U192 and ElectroTos), Improved R4R with Fractal-7 converter (DA96), managed to minimise source noise/jitter using the DAPI receiver and managed to directly drive speakers with the Fractal-31 converter. Most of these improvements are now implemented in our PowerDAC series. Then came the supply chain issues that finally resulted in developing the PowerDAC-X series. The new Fractal-7 matriX converters consist of two fused Fractal-7 converters, the advantages are lower output impedance and only the lowest bits switching around the signal zero crossing for a much cleaner signal. PowerDAC-SX is based on unique Fractal-15 bridge matrix converters where one converter emulates 4 identical power DA converters in bridge configuration, providing up to 2 x 16W rms output power, this DA converter only consumes power when generating signals, because of related reduction in heat dissipation it could be placed in a compact conventional housing.
